Aquatic Coatings: The Complete 2026 Guide to Fish-Safe Polyurea Linings

    Aquatic Coatings:
    Fish-Safe Linings for
    Ponds and Water
    Features

    How spray-applied polyurea creates seamless, non-leaching linings for koi ponds, water features and potable tanks, and how to tell a genuinely fish-safe coating from a label.

    Troy Bacon

    Protective Coatings Specialist, ArmorThane

    14 min read

    Updated August 6, 2026

    Reviewed against ArmorThane product data sheet practice
    Every coating claims to be waterproof. Very few are honestly aquatic. The difference is not marketing, it is duty cycle: an aquatic coating never dries out, never gets a break from hydrostatic pressure, and in most of the applications that matter it shares its water with something alive. A koi that costs more than a used truck does not care how the datasheet reads. It cares whether the film is inert.

    This guide covers what genuinely qualifies a lining for permanent immersion, why cure chemistry decides fish safety more than any label does, how spray-applied polyurea compares with flexible liners, epoxy, cementitious systems and pool paint, and how to prep, spec, budget and commission an aquatic coating properly. Koi ponds get the most attention here because they are the most demanding aquatic feature a coating can be asked to serve.
    Technical graphic showing 100 percent solids, ANSI NSF 61 potable approval, seamless finish, and minus 20 degree spray capability

    KEY TAKEAWAYS: AQUATIC COATINGS AT A GLANCE

    100%

    Solids content of spray polyurea, so there is no solvent to flash off and nothing to leach after cure

    NSF 61

    AquaShield is ANSI/NSF 61 approved for direct potable water contact, and meets USDA criteria

    Seamless

    Sprayed monolithically over concrete, block, steel, foam and shotcrete rockwork with no seams

    -20°F

    AquaShield gel time is fast enough to spray in temperatures down to minus 20 degrees Fahrenheit

    WHAT ACTUALLY MAKES A COATING “AQUATIC”

    Waterproofing and aquatic service are different problems. A basement wall coating spends most of its life damp on one face and dry on the other, and it is allowed to breathe. An aquatic coating is submerged on one face permanently, often under several feet of head pressure, and it is never allowed to dry. That single change in duty cycle eliminates most of the product shelf.

    Four requirements separate a genuine aquatic lining from a coating that merely resists water:

    01

    Hydrolytic stability

    The polymer backbone has to be indifferent to standing water. Some chemistries slowly revert, soften or saponify under constant immersion, which shows up as blistering and chalking long before the warranty is up.

    02

    Wet adhesion

    Dry bond strength is easy. Holding that bond while the substrate is saturated and water is trying to migrate underneath is the real test, and it is why substrate moisture and profile matter so much.

    03

    Inertness after cure

    Nothing may migrate out of the film into the water: no residual solvent, no unreacted monomer, no plasticiser, no heavy-metal pigment. This is where third-party certification earns its keep.

    04

    Crack and
    movement tolerance

    Concrete ponds move with temperature, ground load and water load. A rigid film telegraphs every shrinkage crack. An elastomeric film bridges them and keeps the water where it belongs.

    05

    Geometry tolerance

    Real water features are not flat. Caves, undercuts, boulders, vertical walls and negative-edge details all need a coating that builds film without sagging or thinning at the shoulder.

    06

    Repairability

    Anything submerged eventually gets damaged. A lining that can be feathered, patched and re-sprayed in place without draining and rebuilding the whole feature is worth a premium.
    Spray polyurea satisfies all six because of how it cures. It is a two-component, 100% solids elastomer that reacts on contact rather than drying, so it develops film thickness in one pass, gels in seconds, and tolerates cold and damp conditions that would ruin an epoxy or a paint. ArmorThane covers the same ground on land in the foundation waterproofing guide and in flood control infrastructure; aquatic work simply removes the coating’s permission to ever dry out.
    Infographic outlining hydrolytic stability, wet adhesion, chemical inertness, crack bridging, geometry tolerance, and repairability

    THE FISH-SAFETY QUESTION:
    CURE CHEMISTRY BEATS LABELS

    “Fish safe” and “pond safe” are not regulated terms. Anyone can print them. What actually determines whether a lining will harm livestock is whether the film is completely reacted and whether it contained anything mobile to begin with.

    Where toxicity actually comes from

    Residual solvent. Solvent-borne pond paints and many industrial coatings carry 25 to 60 percent volatile content. Most of it flashes off, but immersion before it is fully gone drives it into the water. This is the classic cause of fish loss after a “quick” pond repaint.

    Unreacted components. A two-part system that was mis-metered, cold, or badly mixed leaves free amine or free resin in the film. This is a metering and equipment problem, not a chemistry problem, and it is why plural-component spray with calibrated proportioners matters.

    Plasticiser migration. Flexible films that get their stretch from added plasticiser rather than from the polymer backbone can weep that plasticiser out over time. Polyurea gets its elongation from its own segmented structure, so there is nothing to migrate.

    Pigments and driers. Older marine and industrial finishes used copper, zinc, lead or tin compounds deliberately, because they are biocides. Anything antifouling is by definition designed to poison aquatic organisms and has no business in a koi pond.

    Substrate leachate. Fresh concrete and mortar drive pH toward 11 or higher and will kill fish on their own. A continuous lining is actually the fix, because it isolates the water from the cementitious substrate entirely.

    The certification that means something: ANSI/NSF 61 is a third-party extraction test. Samples of the cured coating are soaked and the
    water is then analysed for regulated contaminants against drinking-water limits. A product that passes NSF 61 for potable water contact
    has cleared a bar written to protect humans drinking the water for a lifetime. AquaShield carries that approval, which is why it is specified
    for potable tanks and pipe as well as for landscape water features.

    Never use an antifouling, algaecidal or “self-cleaning” marine hull coating in a pond, aquarium or any closed aquatic system. Those products work by continuously releasing biocide. In a closed system with no dilution, that is exactly what you do not want.
    ANSI NSF 61 certified seal and graphic explaining non-leaching cure chemistry for koi fish safety

    AQUATIC COATING COMPARISON:
    POLYUREA VS. LINER VS. EPOXY VS. POOL PAINT

    Most people specifying an aquatic lining are choosing between five or six families. The attributes that actually decide the outcome are how the system handles seams, how much movement it tolerates, whether it can follow complex geometry, and whether it is certified for contact with living things. Everything else is detail.

    Comparison of aquatic lining families for ponds, water features and containment. Ranges are typical of each class, not single-product specifications. Confirm
    against the current product data sheet before you write a spec.

    SYSTEM SEAMS & FAILURE POINTS CRACK BRIDGING COMPLEX GEOMETRY FISH & POTABLE RATING RETURN TO SERVICE TYPICAL SERVICE LIFE
    Spray polyurea
    (AquaShield)
    BEST FIT
    None. Monolithic and fully bonded, including at penetrations Excellent. High elongation bridges shrinkage cracks Excellent. Sprays caves, undercuts and vertical rockwork without sagging ANSI/NSF 61 approved for potable water; meets USDA criteria; odorless, no toxic vapors Hours. Walk-on fast, fillable in about a day in many cases 20 to 30+ years
    EPDM or RPE
    flexible liner
    Many. Seam tape, folds and boots at every pipe are the usual leak sources Good, but unbonded, so a leak travels under the whole sheet Poor. Must be pleated and folded; cannot follow undercuts Generally inert if fish-grade material is specified Immediate 15 to 25 years
    100% solids epoxy None if properly applied, but brittle at joints Poor. Rigid film telegraphs and cracks with substrate movement Fair. Sags on vertical work; needs multiple coats Some grades are NSF 61 certified; requires exact metering and full cure Days. Long cure and temperature sensitive 10 to 20 years
    Cementitious or
    crystalline
    None, but relies on substrate integrity Poor to fair. Moves with the concrete rather than over it Good. Trowel or spray applied Generally safe once pH has stabilised, which takes weeks of flushing Weeks of curing and pH flushing 10 to 20 years
    Pool paint (acrylic,
    epoxy or
    chlorinated
    rubber)
    None, but very thin film with no reserve Very poor. Follows every crack Good on smooth shells, poor on rockwork Varies widely; solvent-borne grades are a real risk to livestock until fully cured Days, plus flushing 2 to 7 years
    Fiberglass (GRP) Laps and joints between mats Poor. Rigid and prone to osmotic blistering Poor. Labour intensive on irregular shapes Inert once fully cured; styrene odour during work Days 15 to 25 years

    How to read this table: flexible sheet liner is genuinely the cheapest way to hold water in a simple, regular, rectangular basin with no rockwork and no penetrations. The moment the design includes a waterfall, a cave, a bog shelf, a skimmer, bottom drains or a formal edge
    detail, the seam count climbs and sheet liner starts losing on both reliability and installed cost. That crossover point is where sprayed
    AquaShield becomes the obvious answer.

    POLYUREA KOI PONDS:
    CURE CHEMISTRY BEATS LABELS

    Koi keeping is where aquatic coatings get judged hardest. A mature koi collection represents years of selection and real money, the fish live for decades, and the water chemistry is a managed biological system rather than a swimming pool. Koi keepers also drain and inspect their ponds more often than any other pond owner, so they find out quickly whether a lining is holding up.

    The traditional options all have a specific failure mode that koi people know by heart. Sheet liner develops pinhole leaks at the folds and pulls away at the bottom drain boot. Concrete alone leaches lime and cracks. Fiberglass blisters and delaminates at the waterline. Pool paint chalks, then sheds into the filter. Sprayed polyurea removes every one of those failure points at once, which is why building a polyurea koi pond has become a standard approach rather than an experiment.
    Diagram showing beneficial Nitrosomonas and Nitrobacter bacterial colonies adhering to non-biocidal polyurea pond walls
    A sprayed polyurea koi pond lining is continuous from floor to coping, so there are no liner folds or seam tape to leak.
    Continuous spray polyurea membrane running seamlessly from pond floor over coping stone and around bottom drains
    AquaShield is ANSI/NSF 61 approved for direct potable water contact, which is a far stricter benchmark than pond safe.

    The seam problem is the whole problem

    In a koi pond, water does not usually escape through the middle of a flat surface. It escapes at transitions: where the wall meets the floor, where the bottom drain penetrates, where the skimmer box is set into the wall, where the waterfall weir meets the pond shell, and where a formal coping edge returns over the top. Every one of those is a detail that sheet liner has to solve with a mechanical fitting, a fold, or seam tape.

    A sprayed lining solves all of them the same way: it simply continues. The film runs up the wall, over the radius, around the drain flange, into the skimmer throat and out over the coping in one continuous membrane that is chemically bonded to the substrate. There is no path for water to travel because there is no interface for it to travel along. If the film is ever breached, the leak stays local instead of migrating behind an unbonded sheet.

    Roof & Exterior Waterproofing

    A koi pond runs on bacteria. Nitrosomonas and Nitrobacter colonies convert fish waste ammonia to nitrite and then to relatively harmless nitrate, and those colonies live on every hard surface in the system, including the pond walls. Two coating properties matter here and they pull in opposite directions.
  • The film must not shed. A chalking or slowly dissolving surface continuously doses the biofilter with debris and can disrupt colonies. A fully cured polyurea does not chalk in immersion, and an aliphatic topcoat can be added where sunlight exposure and colour retention matter.
  •
  • The film must not be antimicrobial. This is the mistake people make when they reach for a “mould and mildew resistant” product. Anything that suppresses bacterial growth is working directly against your nitrogen cycle. You want an inert surface, not a hostile one.
  •
  • A slight profile helps. A smooth but not glassy finish gives bacteria something to hold while still letting solids move toward the bottom drain instead of settling. Texture can be dialled in through spray technique and, where grip is wanted on shelves and steps, with an aggregate broadcast.
  • Ammonia, pH swings and dissolved metals

    Koi water sits around pH 7.0 to 8.5 with meaningful alkalinity, and it carries ammonia and nitrite continuously between water changes. That is a mildly aggressive, biologically active environment. Polyurea is chemically stable across that range and is unaffected by the ammonia concentrations a pond will ever see. Just as importantly, a continuous lining stops the substrate from participating: no lime leaching from new concrete or block, and no iron staining or dissolved metal from rebar, steel tanks or old galvanised fittings. In a new-build concrete pond that isolation alone shortens commissioning from weeks of flushing to days.

    Rockwork, caves and the things koi actually use

    Modern koi and hybrid ornamental ponds are rarely bare boxes. They have overhangs to give fish shade and protection from herons, planted bog shelves, gravel beaches, streams and waterfalls. This is exactly where sheet liner becomes a pleating exercise and where a fast-gelling sprayed film is at its best: AquaShield can be applied in single or multiple passes without appreciable sagging, so a vertical cave wall or the underside of an overhang builds the same film thickness as the pond floor. Sprayed over shotcrete or over rigid foam carving, the same lining also becomes the structural skin of artificial rockwork, which is how ArmorThane approaches landscape and hardscape features generally.

    A note on retrofits: you do not usually have to demolish a failing pond. A sound concrete or block shell with cracks, a chalking paint layer, or a tired fiberglass surface can normally be prepared and over-sprayed. The cost driver is preparation and the condition of the existing surface, not the coating itself. Existing sheet liner, however, cannot be coated over and has to come out.

    BEYOND KOI: OTHER AQUATIC
    FEATURES AND WHAT CHANGES

    Koi ponds are the strictest case, but the same lining logic applies across every aquatic asset. What changes from one to the next is which requirement dominates: livestock safety, public-health certification, foot traffic, chemical exposure or sheer scale. Use the tabs below to see what shifts.

    Fast-gelling spray polyurea building uniform thickness over vertical shotcrete rockwork, caves, and waterfall weirs
    Shallow fountain basins cycle wet and dry constantly; an elastomeric lining survives the movement that cracks rigid coatings.
    Multi-panel graphic showcasing fountains, hatchery raceways, zoo aquarium exhibits, water park pools, and potable water cisterns
    Fast gel time lets the film build full thickness on vertical rockwork, undercuts and cave ceilings without sagging.

    What dominates: freeze-thaw and constant wet-dry cycling at the waterline. Architectural fountains are shallow, so they heat and cool fast, splash constantly, and often shut down dry over winter. That cycling destroys rigid coatings at the waterline first.

    What dominates: geometry. Waterfalls, streams and artificial rock have undercuts, vertical faces and knife edges where a coating either builds film or fails. Fast gel time is the whole game.


    What dominates: livestock safety plus abrasion and cleandown. Raceways, tanks and grow-out ponds are pressure washed and sometimes disinfected between cycles, which punishes thin films.

    What dominates: certification and visual quality on complex shapes. Exhibit pools hold sensitive and often irreplaceable animals, sit behind acrylic viewing panels, and are shaped like natural habitat rather than tanks.

    What dominates: chlorinated water, UV, and bare feet. Commercial aquatics combine aggressive water chemistry with heavy public foot traffic and a hard legal duty on slip resistance.

    What dominates: third-party public-health certification. Here the water is destined for people, so the coating has to be approved for direct potable contact and the documentation has to exist
.

    WHAT THE PERFORMANCE NUMBERS MEAN UNDERWATER

    WHAT THE PERFORMANCE NUMBERS
    MEAN UNDERWATER

    Two numbers predict most aquatic coating outcomes. The first is elongation, which tells you whether the film can bridge a concrete crack instead of splitting over it. The second is how long you have to wait before the water and the fish can go back in, which is a project-management number and often the one that decides the job.

    CRACK-BRIDGING CAPABILITY: ELONGATION AT BREAK
    Scale 0–700% · higher = more stretch before tearing
    Flexible spray polyurea (aquatic grade) 300–600%

    Elastomeric; bridges shrinkage cracking in concrete shells

    EPDM / RPE sheet liner 300–500%

    Stretchy but unbonded, so movement is not transferred to the substrate

    Pool paint (acrylic / chlorinated rubber) 5–15%

    Thin film with almost no reserve; follows every crack

    100% solids epoxy 2–5%

    Rigid; telegraphs substrate movement

    Fiberglass (GRP) 1–3%

    Rigid laminate; prone to osmotic blistering in immersion

    Cementitious / crystalline 0–2%

    Moves with the concrete rather than over it

    TYPICAL WAIT FROM FINAL COAT TO SAFE FIRST FILL
    Scale 0–30 days · lower = faster return to service
    EPDM / RPE sheet liner Immediate

    No cure period; the trade-off is seams

    Spray polyurea About 1 day

    Cures by reaction, not evaporation; nothing left to flash off

    Fiberglass (GRP) 3–7 days

    Styrene must fully cure out

    100% solids epoxy 5–10 days

    Temperature dependent; full chemical cure required before immersion

    Pool paint 5–14 days

    Solvent must fully leave the film, then flush

    Cementitious / new concrete 14–28 days +

    Plus repeated fill-and-dump cycles to bring pH down

    Read these as class ranges, not product specifications. Every family spans a wide performance band depending on formulation, film
    thickness and temperature, and published test values are laboratory numbers measured to standards such as ASTM D412 for tensile and
    elongation. Before you write a specification, pull the current product data sheet for the exact grade you intend to use and confirm the
    values, the required dry film thickness and the immersion service statement. For a worked example of how ArmorThane publishes
    measured properties, see the tensile and elongation panels in the foundation waterproofing guide.

    The number that is not on any datasheet

    The number that is not on
    any datasheet

    Seam count. It is the strongest single predictor of whether an aquatic feature leaks in year three, and no product sheet reports it because it is a function of your design, not the material. Count every lap, fold, pipe boot, corner and mechanical termination in your proposed build. If that number is larger than about a dozen, a bonded seamless membrane will almost certainly outlive a sheet system regardless of what the elongation figures say.

    SURFACE PREP AND APPLICATION
    SPEC FOR AQUATIC WORK

    Coating failures in aquatic service are almost never formulation failures. They are preparation failures, and they concentrate in three places: moisture in the substrate, contamination on the surface, and geometry that was never detailed properly. Get those three right and the lining does what the datasheet says.

    1. Structure first, coating second

    A coating is a barrier, not a structural repair. Active leaks, moving cracks, spalled concrete, exposed corroded rebar and unsound block all get fixed before anything is sprayed. Structural cracks need routing and filling with an appropriate repair mortar or resin; hairline shrinkage cracking can generally be bridged by the elastomeric film itself. If groundwater is pushing in from behind, relieve or drain it first, because no coating holds against negative-side hydrostatic pressure indefinitely.

    2. Profile and cleanliness

    Concrete and shotcrete: abrasive blast, shot blast or high-pressure water blast to remove laitance, curing compounds, efflorescence and old chalking coatings, and to open a consistent profile. Aim for a uniformly abraded, sound surface with the aggregate just showing.

    Steel: abrasive blast to a near-white or white metal standard depending on service. AquaShield will coat carbon or mild steel without a primer, which removes a full cure step from a tank or pipe job.
    Existing coatings: remove anything that is not tightly adhered. Test adhesion in several places before deciding to overcoat rather than strip.

    Contamination: in a pond that has been in service, algae, biofilm, oils from feed, and mineral scale are all bond breakers. They must come off, and the surface must be rinsed and dried, not just scrubbed.
    Sheet liner: cannot be coated over. It has to come out.

    Interactive pond calculator interface showing wetted surface area calculation with rockwork detail uplift versus water volume

    3. Moisture is the deal breaker

    This is where most aquatic jobs go wrong. Concrete that looks dry can hold enough moisture to drive vapour pressure under a freshly applied film and blow it off the wall. Measure it rather than guessing: use a calcium chloride test or, better, in-situ relative humidity probes drilled into the slab, and compare the result against the coating manufacturer’s stated limit. New concrete needs to cure properly first. Polyurea is relatively insensitive to moisture and temperature compared with epoxy, which widens the working window considerably, but it does not repeal physics. If the substrate is wet, either wait, force-dry it, or specify a moisture-tolerant primer.

    4. Detailing: where the job is actually won

    Cove every inside corner. A sharp 90-degree wall-to-floor junction concentrates stress. A radius or fillet lets the film carry across it at full thickness.

    Terminate above the waterline. Run the lining up and over the coping or into a reglet so the edge is never sitting at the water surface where wet-dry cycling attacks it.

    Reinforce transitions. Around bottom drains, skimmer boxes, returns, jets and bulkhead fittings, embed a reinforcing fabric or detail strip in the film. AquaShield is specifically noted as suitable for installation with or without reinforcement in transitional areas.

    Mask what you are not coating. Overspray from a fast-gelling polyurea is permanent. Acrylic viewing panels, coping stone and equipment need protecting.

    5. Application and film thickness

    Aquatic-grade polyurea is a plural-component material sprayed with heated, high-pressure proportioning equipment at a fixed mix ratio. That equipment requirement is not a formality: correct metering is exactly what guarantees a fully reacted, non-leaching film, which is the whole basis of fish safety. This is applicator work, not a DIY roller job.
    Spec selector widget generating customized dry film thickness, substrate prep, and finish guidelines for aquatic projects

    Ask for the QA record. A professional aquatic installation should hand you substrate moisture readings, ambient and dew point logs, batch numbers, a dry film thickness map and holiday-test results. If a contractor cannot produce those, you have no way to demonstrate the film was fully reacted, which is the one thing that matters for livestock.

    POND AND WATER FEATURE COATING CALCULATOR

    Aquatic coatings are bought by wetted surface area, but almost everyone estimates from water volume, which is why quotes come in short. This calculator works the way an applicator does: it derives the surface the coating actually has to cover, adds an allowance for the rockwork and detail that a plan view hides, and converts that into material at your target film thickness.

    Wetted Area, Volume & Material Estimator

    Enter your dimensions in feet. Results update as you type.

    Freeform assumes a rounded, elliptical footprint
    For a circular basin this is the diameter
    Ignored for circular basins
    Average, not maximum
    Uplift on wetted area for hidden surface
    Confirm against the product data sheet
    534
    Wetted surface area (sq ft) including detail uplift
    5,640
    Approximate water volume (US gallons)
    40.0
    Coating material estimate (gallons, 20% spray loss)
    188
    Plan-view area for comparison (sq ft)
    How to use the output: the gap between the plan-view figure and the wetted-area figure is the number that surprises people, and it is the single most common reason an aquatic coating quote gets revised upward. Material estimates assume a 100% solids product at a theoretical coverage of 1,604 square feet per gallon at one mil, with a 20% allowance for spray loss and profile. Rough shotcrete, deep rock texture and windy conditions all consume more. Treat this as a planning tool and get a site-specific quote before ordering.

    FISH-SAFE COATING SELECTOR

    Answer three questions and this tool assembles the specification notes that actually change from one aquatic job to the next: film thickness, substrate handling, certification requirements and the detailing that most often gets missed.

    Build Your Aquatic Spec

    Select one option in each row.

    Koi / ornamental pond — sprayed polyurea aquatic lining

    Suggested dry film thickness: 100 mils. Certification: Specify an ANSI/NSF 61 approved lining. It is well above pond-safe and it is the only claim backed by third-party extraction testing.

    Substrate handling: Abrasive or water blast to remove laitance and curing compounds, then verify substrate moisture with in-situ RH probes or a calcium chloride test before spraying. Repair spalls and route moving cracks first.

    Finish and exposure: An aromatic polyurea such as AquaShield is mechanically and dimensionally stable here. It may shift shade over time, which does not affect performance.

    Detailing checklist:

    • Cove all wall-to-floor junctions so the film carries across at full thickness.
    • Embed reinforcement at bottom drains, skimmer throats and returns.
    • Holiday-test the finished lining before stocking; a pinhole is cheap now and expensive later.
    • Do not use anything antimicrobial, algaecidal or antifouling. It will fight your biofilter.

    Review the AquaShield product page and confirm every value against the current product data sheet before issuing a specification.

    Fountain / water feature — sprayed polyurea aquatic lining

    Suggested dry film thickness: 80 mils. Certification: NSF 61 approval is not usually mandatory but it is the cleanest way to prove the film is inert.

    Substrate handling: Abrasive or water blast to remove laitance and curing compounds, then verify substrate moisture with in-situ RH probes or a calcium chloride test before spraying. Repair spalls and route moving cracks first.

    Finish and exposure: An aromatic polyurea such as AquaShield is mechanically and dimensionally stable here. It may shift shade over time, which does not affect performance.

    Detailing checklist:

    • Detail the waterline carefully; shallow basins cycle wet and dry constantly and fail there first.
    • Terminate the lining above the water level, over the coping or into a reglet.
    • Line the sump and equipment vault while access is open.

    Review the AquaShield product page and confirm every value against the current product data sheet before issuing a specification.

    Aquaculture / hatchery — sprayed polyurea aquatic lining

    Suggested dry film thickness: 100 mils. Certification: Specify ANSI/NSF 61 approval and confirm the product meets USDA criteria for the facility type.

    Substrate handling: Abrasive or water blast to remove laitance and curing compounds, then verify substrate moisture with in-situ RH probes or a calcium chloride test before spraying. Repair spalls and route moving cracks first.

    Finish and exposure: An aromatic polyurea such as AquaShield is mechanically and dimensionally stable here. It may shift shade over time, which does not affect performance.

    Detailing checklist:

    • Cove every corner so raceways and tanks can be fully cleaned down.
    • Confirm resistance to your disinfection routine and pressure-wash pressures.
    • No biocidal additives at any stocking density.

    Review the AquaShield product page and confirm every value against the current product data sheet before issuing a specification.

    Zoo / aquarium exhibit — sprayed polyurea aquatic lining

    Suggested dry film thickness: 100 mils. Certification: ANSI/NSF 61 approval is effectively the baseline expectation for animal habitat water.

    Substrate handling: Abrasive or water blast to remove laitance and curing compounds, then verify substrate moisture with in-situ RH probes or a calcium chloride test before spraying. Repair spalls and route moving cracks first.

    Finish and exposure: An aromatic polyurea such as AquaShield is mechanically and dimensionally stable here. It may shift shade over time, which does not affect performance.

    Detailing checklist:

    • Mask acrylic viewing panels; polyurea overspray is permanent.
    • Keep the film continuous and flexible across window frames and bulkheads.
    • Coordinate with life-support penetrations before spraying.

    Review the AquaShield product page and confirm every value against the current product data sheet before issuing a specification.

    Pool / water park — sprayed polyurea aquatic lining

    Suggested dry film thickness: 60 to 80 mils. Certification: Verify chemical resistance to your chlorine or bromine regime and any shock dosing.

    Substrate handling: Abrasive or water blast to remove laitance and curing compounds, then verify substrate moisture with in-situ RH probes or a calcium chloride test before spraying. Repair spalls and route moving cracks first.

    Finish and exposure: An aromatic polyurea such as AquaShield is mechanically and dimensionally stable here. It may shift shade over time, which does not affect performance.

    Detailing checklist:

    • Specify a slip-resistant finish on decks, steps, ramps and zero-depth entries.
    • Plan the shutdown window; fast return to service is the main commercial advantage here.
    • Detail expansion joints rather than simply coating over them.

    Review the AquaShield product page and confirm every value against the current product data sheet before issuing a specification.

    Potable tank / cistern — sprayed polyurea aquatic lining

    Suggested dry film thickness: 80 to 100 mils. Certification: ANSI/NSF 61 approval for direct potable water contact is mandatory. Keep the documentation for your records.

    Substrate handling: Abrasive or water blast to remove laitance and curing compounds, then verify substrate moisture with in-situ RH probes or a calcium chloride test before spraying. Repair spalls and route moving cracks first.

    Finish and exposure: An aromatic polyurea such as AquaShield is mechanically and dimensionally stable here. It may shift shade over time, which does not affect performance.

    Detailing checklist:

    • AquaShield suits tanks from 5 gallons upward and potable pipe 9 inches in diameter and larger.
    • Ventilate and follow confined-space procedure inside closed tanks.
    • Record batch numbers and film thickness for the compliance file.

    Review the AquaShield product page and confirm every value against the current product data sheet before issuing a specification.

    Koi / ornamental pond — sprayed polyurea aquatic lining

    Suggested dry film thickness: 100 mils. Certification: Specify an ANSI/NSF 61 approved lining. It is well above pond-safe and it is the only claim backed by third-party extraction testing.

    Substrate handling: Abrasive or water blast to remove laitance and curing compounds, then verify substrate moisture with in-situ RH probes or a calcium chloride test before spraying. Repair spalls and route moving cracks first.

    Finish and exposure: An aromatic polyurea such as AquaShield is mechanically and dimensionally stable here. It may shift shade over time, which does not affect performance.

    Detailing checklist:

    • Cove all wall-to-floor junctions so the film carries across at full thickness.
    • Embed reinforcement at bottom drains, skimmer throats and returns.
    • Holiday-test the finished lining before stocking; a pinhole is cheap now and expensive later.
    • Do not use anything antimicrobial, algaecidal or antifouling. It will fight your biofilter.

    Review the AquaShield product page and confirm every value against the current product data sheet before issuing a specification.

    Koi / ornamental pond — sprayed polyurea aquatic lining

    Suggested dry film thickness: 100 mils. Certification: Specify an ANSI/NSF 61 approved lining. It is well above pond-safe and it is the only claim backed by third-party extraction testing.

    Substrate handling: Fill and level the block face first. Open-textured masonry needs a parge or block filler or the film will bridge voids and pinhole.

    Finish and exposure: An aromatic polyurea such as AquaShield is mechanically and dimensionally stable here. It may shift shade over time, which does not affect performance.

    Detailing checklist:

    • Cove all wall-to-floor junctions so the film carries across at full thickness.
    • Embed reinforcement at bottom drains, skimmer throats and returns.
    • Holiday-test the finished lining before stocking; a pinhole is cheap now and expensive later.
    • Do not use anything antimicrobial, algaecidal or antifouling. It will fight your biofilter.

    Review the AquaShield product page and confirm every value against the current product data sheet before issuing a specification.

    Koi / ornamental pond — sprayed polyurea aquatic lining

    Suggested dry film thickness: 100 mils. Certification: Specify an ANSI/NSF 61 approved lining. It is well above pond-safe and it is the only claim backed by third-party extraction testing.

    Substrate handling: Abrasive blast to the specified cleanliness standard. AquaShield bonds to carbon and mild steel without a primer, which removes a cure step from the schedule.

    Finish and exposure: An aromatic polyurea such as AquaShield is mechanically and dimensionally stable here. It may shift shade over time, which does not affect performance.

    Detailing checklist:

    • Cove all wall-to-floor junctions so the film carries across at full thickness.
    • Embed reinforcement at bottom drains, skimmer throats and returns.
    • Holiday-test the finished lining before stocking; a pinhole is cheap now and expensive later.
    • Do not use anything antimicrobial, algaecidal or antifouling. It will fight your biofilter.

    Review the AquaShield product page and confirm every value against the current product data sheet before issuing a specification.

    Koi / ornamental pond — sprayed polyurea aquatic lining

    Suggested dry film thickness: 100 mils. Certification: Specify an ANSI/NSF 61 approved lining. It is well above pond-safe and it is the only claim backed by third-party extraction testing.

    Substrate handling: Abrade thoroughly and test adhesion in several locations. Remove any blistered or delaminated laminate rather than coating over it.

    Finish and exposure: An aromatic polyurea such as AquaShield is mechanically and dimensionally stable here. It may shift shade over time, which does not affect performance.

    Detailing checklist:

    • Cove all wall-to-floor junctions so the film carries across at full thickness.
    • Embed reinforcement at bottom drains, skimmer throats and returns.
    • Holiday-test the finished lining before stocking; a pinhole is cheap now and expensive later.
    • Do not use anything antimicrobial, algaecidal or antifouling. It will fight your biofilter.

    Review the AquaShield product page and confirm every value against the current product data sheet before issuing a specification.

    Koi / ornamental pond — sprayed polyurea aquatic lining

    Suggested dry film thickness: 100 mils. Certification: Specify an ANSI/NSF 61 approved lining. It is well above pond-safe and it is the only claim backed by third-party extraction testing.

    Substrate handling: Confirm the foam density and compressive strength will carry the loads, then spray the lining as a continuous structural skin over the carved profile.

    Finish and exposure: An aromatic polyurea such as AquaShield is mechanically and dimensionally stable here. It may shift shade over time, which does not affect performance.

    Detailing checklist:

    • Cove all wall-to-floor junctions so the film carries across at full thickness.
    • Embed reinforcement at bottom drains, skimmer throats and returns.
    • Holiday-test the finished lining before stocking; a pinhole is cheap now and expensive later.
    • Do not use anything antimicrobial, algaecidal or antifouling. It will fight your biofilter.

    Review the AquaShield product page and confirm every value against the current product data sheet before issuing a specification.

    Koi / ornamental pond — sprayed polyurea aquatic lining

    Suggested dry film thickness: 100 mils. Certification: Specify an ANSI/NSF 61 approved lining. It is well above pond-safe and it is the only claim backed by third-party extraction testing.

    Substrate handling: Existing sheet liner cannot be coated over and must be removed completely. Expect to expose and repair the shell underneath before lining.

    Finish and exposure: An aromatic polyurea such as AquaShield is mechanically and dimensionally stable here. It may shift shade over time, which does not affect performance.

    Detailing checklist:

    • Cove all wall-to-floor junctions so the film carries across at full thickness.
    • Embed reinforcement at bottom drains, skimmer throats and returns.
    • Holiday-test the finished lining before stocking; a pinhole is cheap now and expensive later.
    • Do not use anything antimicrobial, algaecidal or antifouling. It will fight your biofilter.

    Review the AquaShield product page and confirm every value against the current product data sheet before issuing a specification.

    Koi / ornamental pond — sprayed polyurea aquatic lining

    Suggested dry film thickness: 100 mils. Certification: Specify an ANSI/NSF 61 approved lining. It is well above pond-safe and it is the only claim backed by third-party extraction testing.

    Substrate handling: Abrasive blast to the specified cleanliness standard. AquaShield bonds to carbon and mild steel without a primer, which removes a cure step from the schedule.

    Finish and exposure: An aromatic polyurea such as AquaShield is mechanically and dimensionally stable here. It may shift shade over time, which does not affect performance.

    Detailing checklist:

    • Cove all wall-to-floor junctions so the film carries across at full thickness.
    • Embed reinforcement at bottom drains, skimmer throats and returns.
    • Holiday-test the finished lining before stocking; a pinhole is cheap now and expensive later.
    • Do not use anything antimicrobial, algaecidal or antifouling. It will fight your biofilter.

    Review the AquaShield product page and confirm every value against the current product data sheet before issuing a specification.

    Koi / ornamental pond — sprayed polyurea aquatic lining

    uggested dry film thickness: 100 mils. Certification: Specify an ANSI/NSF 61 approved lining. It is well above pond-safe and it is the only claim backed by third-party extraction testing.

    Substrate handling: Abrasive blast to the specified cleanliness standard. AquaShield bonds to carbon and mild steel without a primer, which removes a cure step from the schedule.

    Finish and exposure: Add an aliphatic topcoat over the aromatic base to hold colour and gloss in sunlight. ArmorThane offers aliphatic and UV-stable options for exactly this.

    Detailing checklist:

    • Cove all wall-to-floor junctions so the film carries across at full thickness.
    • Embed reinforcement at bottom drains, skimmer throats and returns.
    • Holiday-test the finished lining before stocking; a pinhole is cheap now and expensive later.
    • Do not use anything antimicrobial, algaecidal or antifouling. It will fight your biofilter.

    Review the AquaShield product page and confirm every value against the current product data sheet before issuing a specification.

    Koi / ornamental pond — sprayed polyurea aquatic lining

    Suggested dry film thickness: 100 mils. Certification: Specify an ANSI/NSF 61 approved lining. It is well above pond-safe and it is the only claim backed by third-party extraction testing.

    Substrate handling: Abrasive blast to the specified cleanliness standard. AquaShield bonds to carbon and mild steel without a primer, which removes a cure step from the schedule.

    Finish and exposure: Broadcast aggregate into the wet film on any walkable surface, then topcoat. Specify and document the slip-resistance level you need.

    Detailing checklist:

    • Cove all wall-to-floor junctions so the film carries across at full thickness.
    • Embed reinforcement at bottom drains, skimmer throats and returns.
    • Holiday-test the finished lining before stocking; a pinhole is cheap now and expensive later.
    • Do not use anything antimicrobial, algaecidal or antifouling. It will fight your biofilter.

    Review the AquaShield product page and confirm every value against the current product data sheet before issuing a specification.

    Step-by-step visual sequence from spark testing and 24-hour leak test rinse to filter seeding and gradual fish stocking

    WHAT AQUATIC COATINGS COST,
    AND WHAT DRIVES THE PRICE

    WHAT AQUATIC COATINGS COST, AND WHAT DRIVES THE PRICE

    There is no honest flat square-foot number for aquatic linings, and any quote that opens with one has not looked at the feature. Two ponds with identical water volume can differ by a factor of three in installed cost because one is a smooth rectangular box and the other is a freeform build with a cave, a waterfall and eleven penetrations. These are the variables that actually move the number, roughly in order of impact.

    01

    Surface preparation

    Routinely the largest single line item, and the one that varies most. Blasting a sound new shell is straightforward. Stripping failed pool paint, grinding off old fiberglass, or chasing and repairing cracks in a forty-year-old shell is a different job entirely.

    02

    Geometry and access

    Wetted area is the billing unit, and rockwork, caves, shelves and streams can add 40 to 60 percent over the plan view. A pond in a tight courtyard with no hose or equipment access costs more than the same pond on open ground.

    03

    Film thickness
    and product

    A koi pond at 100 mils uses substantially more material than a decorative basin at 60. An aliphatic topcoat for colour retention is an added layer with its own labour and material cost.

    04

    Detailing and
    penetrations

    Every bottom drain, skimmer, return, jet and bulkhead is hand-detailed and often reinforced. Penetration count is a better cost predictor than square footage on small, complex features.

    05

    Structural repair

    Anything the coating cannot fix has to be fixed first. Spalled concrete, exposed rebar, unsound block and active groundwater infiltration are separate scopes that get priced separately.

    06

    Downtime value

    Rarely on the invoice, frequently the deciding factor. A commercial feature that reopens in days rather than weeks recovers revenue that easily outweighs the coating premium.

    The fair way to compare bids is on lifecycle cost, not first cost. Pool paint is the cheapest thing you can put in a pond and you will do it again in three to seven years, every time draining the feature, disturbing the livestock and paying for preparation all over again. A properly installed spray polyurea lining is a larger single outlay measured in decades. Across a twenty-year horizon the paint route is usually the more expensive one, and that is before you price the risk of a leak under a rockwork feature you cannot easily open up.

    What to ask for in a quote: wetted square footage as measured rather than estimated from volume, the specified product and dry film thickness, the preparation method, how penetrations and inside corners will be detailed, whether holiday testing is included, the QA documentation you will receive, and the warranty terms with their exclusions. A bid that omits film thickness is not a specification, it is a guess.

    CURING, LEACHING AND THE FIRST FILL

    The most anxious moment in any aquatic coating project is deciding when it is safe to put the water and the animals back. The honest answer depends entirely on what was applied, because the mechanism of cure decides the risk.

    Why polyurea shortens this window

    Solvent-borne coatings become safe by evaporation, and evaporation is slow, temperature dependent and hard to verify. A 100% solids polyurea becomes safe by chemical reaction, and that reaction is essentially complete within hours. There is no solvent to leave, no film to keep hardening for weeks, and nothing that continues to migrate. That is why a properly sprayed lining can often be filled the following day rather than after a fortnight of waiting and flushing.

    A sensible commissioning sequence

    Inspect and test first. Confirm dry film thickness across the feature and holiday-test for pinholes before any water goes in. Fixing a defect in a dry, empty pond is trivial.

    Fill and hold. Fill the feature and leave it standing for 24 to 48 hours as a leak test and a rinse. Check the level against a mark rather than trusting your eye.

    Dump the first fill. Discard that water rather than keeping it. It has rinsed construction dust, blast media and handling residue off the surface, none of which is a coating problem but none of which belongs in your pond.

    Refill, then run the system. Bring pumps, filters and UV online and let the water circulate. Dechlorinate if you are on municipal supply.

    Verify chemistry before livestock. Check pH, ammonia, nitrite and temperature and confirm they are stable. On a new concrete build, a continuous lining should mean pH is already stable rather than climbing, which is one of the practical benefits of isolating the substrate.

    Re-establish the biofilter, then stock gradually. Seed the filter, add fish in stages, and keep testing. Rushing this step, not the coating, is what most often causes losses after a rebuild.

    Never stock valuable fish directly into a freshly commissioned system on the strength of the coating alone. Even a perfectly inert lining cannot compensate for an immature biofilter. Follow your normal fishless cycling or filter-seeding routine and confirm ammonia and nitrite are reading zero before the koi go back in.

    Proper soil slope grading and gutter downspout extensions directing water away from a home foundation.

    AQUATIC COATINGS: FREQUENTLY ASKED QUESTIONS

    Aquatic coatings are protective linings engineered for permanent immersion rather than occasional wetting. To qualify, a system has to resist hydrolysis, keep its bond while the substrate is saturated, tolerate the movement of a water-loaded concrete shell, and stay chemically inert so that nothing migrates out of the film into the water. They are used in koi and ornamental ponds, fountains and water features, aquaculture tanks, zoo and aquarium exhibits, pools and water parks, potable water tanks and pipe, cisterns, canals and containment basins.

    A correctly applied, fully cured polyurea is inert and safe for fish. The reason is its cure chemistry: it is a 100% solids, two-component elastomer that reacts on contact rather than drying, so there is no solvent to flash off and nothing left unreacted to leach. The qualifier matters, though. Safety depends on accurate metering and mixing, which is why aquatic polyurea is sprayed with calibrated plural-component equipment rather than rolled on. Look for a product with third-party certification: ArmorThane AquaShield is ANSI/NSF 61 approved for direct contact with potable water, a considerably stricter test than any informal pond-safe claim.

    Yes, and it is now a mainstream approach rather than an experiment. Polyurea is sprayed as a seamless membrane over concrete, block, shotcrete or carved foam, which removes the failure points koi keepers know best: pinhole leaks at liner folds, pull-away at the bottom drain boot, lime leaching from bare concrete, and chalking paint shedding into the biofilter. Because the film is continuous and bonded, any future damage stays local instead of travelling behind an unbonded sheet.

    With a 100% solids polyurea the coating itself is typically ready for water within about a day, because it cures by chemical reaction rather than evaporation. The sensible sequence is to holiday-test the lining, fill and hold for 24 to 48 hours as a leak test and rinse, dump that first fill, refill and dechlorinate, run the filtration, then confirm pH, ammonia and nitrite are stable before stocking. In practice the limiting factor is almost never the coating. It is the maturity of your biofilter.

    It depends on the design. For a simple rectangular basin with no rockwork and no penetrations, sheet liner is cheaper and perfectly serviceable. Once the design includes a waterfall, a cave, bog shelves, a skimmer, bottom drains or a formal edge, the seam count rises sharply and every seam, fold and pipe boot becomes a potential leak. A sprayed lining has none, and it is bonded, so leaks cannot migrate. Count the laps, folds and penetrations in your build: if the total is more than about a dozen, a seamless bonded membrane will usually outlast the sheet.

    Usually yes, and retrofitting is one of its strongest use cases. A sound concrete or block shell with shrinkage cracks, a chalking paint layer, or tired fiberglass can normally be prepared and over-sprayed without demolition. The work is in the preparation: blasting off laitance, failed coatings and biofilm, repairing spalls and routing moving cracks, abrading and adhesion-testing fiberglass, and verifying substrate moisture. The one exception is existing sheet liner, which cannot be coated over and has to be removed.

    NSF/ANSI 61 is a third-party extraction standard. Samples of the cured coating are soaked and the water is then analysed for regulated contaminants against drinking-water limits. Passing it means the film has been independently shown not to release anything harmful at levels of concern to people drinking that water for a lifetime. Nothing about a pond requires that certification, but it is the most rigorous inertness evidence commonly available, so it is a far better buying signal than an unregulated fish-safe label.

    uty features are often specified around 60 to 80 mils, standard ponds and potable tanks around 80 to 100 mils, and koi ponds, aquaculture and severe service at 100 mils or more. Always confirm the figure against the current data sheet for the exact grade, measure wet film thickness during application, and verify dry film thickness afterwards, because thin spots at radii and shoulders are the usual defect.

    Not realistically. Aquatic-grade polyurea is a plural-component material sprayed with heated, high-pressure proportioning equipment that holds a fixed mix ratio, and gel times are measured in seconds. Correct metering is precisely what guarantees a fully reacted, non-leaching film, so the equipment requirement is a safety requirement rather than a formality. There are DIY pond paints, but they are a different class of product with a much shorter life and a real risk to livestock if immersed before they are fully cured.

    A properly prepared and correctly applied spray polyurea lining in continuous immersion is generally expected to give 20 to 30 years or more of service. Sheet liner typically runs 15 to 25 years, epoxy and fiberglass 10 to 20, and pool paint 2 to 7. Those are class expectations rather than guarantees, and the dominant variable is not the product. It is preparation, film thickness and detailing.

    Yes, and that is one of its practical advantages. Fresh concrete and mortar drive pH upward and can leach lime into the water, which is why new bare-concrete ponds normally need weeks of repeated filling, flushing and testing. A continuous bonded lining isolates the water from the cementitious substrate entirely, so the substrate stops participating in your water chemistry. It also prevents iron staining from rebar and dissolved metals from steel fittings.

    This is where it separates itself most clearly. Fast gel time means the material can be sprayed on vertical faces, undercuts and the underside of overhangs while still building the specified film thickness without appreciable sagging. Applied over shotcrete, mortar-carved rock or rigid foam, the lining becomes both the waterproofing and the structural skin of the feature, which removes the hidden liner folds behind rockwork that cause the classic disappearing-stream leak.

    THE BOTTOM LINE ON AQUATIC COATINGS

    Talk to ArmorThane

    If you run grain storage or coat it for a living, ArmorThane can help you spec the right system for the surface, from exterior corrosion protection to the food-contact question on the inside.

    CONTACT US

    REQUEST A QUOTE OR

    BECOME AN APPLICATOR

    ArmorThane has built a strong reputation over the past 30 years for producing high-quality, durable protective coatings.

    group 115 660555abebfe4
    Phone Number

    Tel: 417.831.5090

    group 115 1 660556c21395c
    Email Us

    moreinfo@armorthane.com

    Step 1 of 3

    To help us prepare for a discussion with you, please provide some information on the type of Protective Coating business you are considering, including where your business would be located.

    RV Find An Applicator

    Protective Coating Applications

    Products

    Applicator Opportunities

    Knowledge Center

    Galleries
